U-Line 1175WCB-00 1000 Series Wine Captain 48 Bottle Wine Cellar - Black

Enlarge U-Line 1175WCB-00 1000 Series Wine Captain 48 Bottle Wine Cellar - Black
Enlarge Image

U-Line's 1175WCB-00 Wine Cooler 48-Bottle Wine Refrigerator / Tinted, Thermal-Tempered Glass Door / Beech-Trimmed, Slide-Out Wine Racks / Automatic Defrost / Interior Light / Adjustable Leveling Legs / Field Reversible Door

List Price: $1,711.25
Price: $1,369.00
based on 1 Reviews

Bringing the convenience of a personal wine cellar to any location in the home, this Wine Captain Wine Cellar 1175WCB-00 by U-Line is the perfect companion for entertaining - or just relaxing.

U-Line's unique Triple Temperature Zone Design adds versatility in storage, housing three different types of wine at their optimum serving temperatures, or safely storing a single type of wine throughout the entire cabinet. Push Button Digital Control, integrated in the lower bottle retainer, allows you to set the middle zone temperature and see the temperature in all three zones. Red wines are maintained at approximately 55°F in the top zone, white wines at approximately 50°F in the middle and sparkling wines at approximately 45°F in the bottom. Stable Storage Temperature, Vibration Safe Environment, and 50% Internal Relative Humidity, enable short or longer term storage.

The 1175WCB-00 Wine Cooler offers storage for up to 48 bottles of wine behind a Tinted, Thermal-Tempered Glass Door that protects wines from potentially harmful UV rays. Beech-Trimmed, Slide-Out Wine Racks fully extend for easy access to bottles and can be stained to match surrounding décor. Other features include Automatic Defrost, an Adjustable On/Off Interior Light--permits elegant bottle presentation when door is closed and light will automatically turn off after 4 hrs., Adjustable Leveling Legs, and a Field Reversible Door.

  • Black Vinyl-Clad Steel Cabinet and Black Door Frame
  • Stores Up to 48 Bottles of Wine
  • Unique Triple Temperature Zone Design for Storing Red, White, and Sparkling Wines in One Unit
  • Slide-Out Wine Racks Allow for Easy Access to Bottles
  • Beech-Trimmed Wine Racks Can Be Stained to Match Surrounding Décor
  • Push Button Digital Control Integrated in Lower Bottle Retainer
    • Allows You to Set the Middle Zone Temperature
    • Allows You to See the Temperature in All Three Zones
    • Displays Both Fahrenheit and Celsius
  • Automatic Defrost
  • Maintains Stable Storage Temperature
  • Provides Vibration-Safe Environment for Wines
  • Maintains Approximately 50% Internal Relative Humidity
  • Tinted, Thermal Glass Door Protects Wines From Harmful UV Rays
  • Adjustable On/Off Interior Light Automatically Shuts Off After 4 Hours
  • Field Reversible Door
  • Integrated Door Handle
  • Adjustable Leveling Legs Provide Up to 1" Height Extension
  • Built-in or Freestanding Applications
  • No Additional Clearance or Ventilation For Built-in Installation (Do Not Obstruct Front Grille)
  • UL Listed
  • Installation Requirements: MUST Add 1/4" to Overall Width for Proper Installation


  • MUST add 1/4" to overall width for proper installation
  • Allow 2-1/2" clearance on hinge side for a 90° opening when installed against a wall
  • Front grille/toe kick must be unobstructed for proper ventilation


*Zero clearance on all 2000 Series black or white units when installed with custom full overlay door panel/frame.
*Zero clearance on all 2000 Series and 1000 Series black or white units when installed with a 1/4" flush insert panel. Allow proper clearance for a raised insert panel.
*Allow 2-1/2" clearance, on hinge side, for a 90 degree opening when installed against a wall on all Stainless Steel models.

UPC: 833790003469
Height34 1/8"
Width23 15/16"
Depth23 1/16"
Unit Weight132 lbs.
Shipping Weight132 lbs.
Labor1 Year
Parts1 Year
Compressor (Parts Only)5 Years
Key Features
Built-in CapableYes
Security LockNone
Multiple / Dual ZoneNo
Beverage CenterNo
Cabinet Color / MaterialBlack
Wine Bottle Count48
Cooling System
Defrost SystemAutomatic
Front VentilationYes
Adjustable ThermostatYes
Compartments (Distinct Zones)No
LightingYes, with On/Off Switch
TypeSlide-Out Wire Racks
Number of Shelves5
MaterialVinyl-Coated Metal, Beech Trim
Glide-Out (Roller Assemblies)Yes
TypeThermal Glass Door
Number of Doors1
Color / MaterialBlack
Door HandleRecessed
Field ReversibleYes
Accepts Custom PanelNo
Tinted / UV ProtectiveYes
Electrical Requirements110/115 V, 60 Hz
Running Amps2.4
PDFSpecifications and Features
PDFUse and Care Guide
PDFInstallation Guide

U-Line 1175WCB-00 1000 Series Wine Captain 48 Bottle Wine Cellar - Black Reviews

Average Customer Rating:
(based on 1 reviews)
Good Value - Super Product
by:Jay Sax (07-01-2014)
Anacortes, WA
Comments:I've had a U-Line wine captain for many years. Because it has given me such good service I bought a second U-Line captain. This one lacks some bells and whistles. But that is why it is a good value: It does what it is suppose to do--preserve my wine. I highly recommend U-Line and the Beverage Factory. The service was excellent and the delivery man helped me unpack the captain.
Bottom Line:I would recommend this product.
Shipping Calculator
Enter Your Shipping Zip Code:
Shipping Options
Please enter a zip code.
All charges are based on a quantity of 1.
Click "Add to Cart" above to change quantities
and make actual ship method selection.

Available Options:

Optional Extended Warranty
New Leaf ServicePro 1 Year Extended Warranty [more info] +$24.99
New Leaf ServicePro 3 Year Date of Purchase Warranty [more info] +$49.99
New Leaf ServicePRO 5 Year Date of Purchase Warranty [more info] +$99.99
New Leaf ServicePRO 3 Year Date of Purchase Commercial Warranty [more info] +$145.98
New Leaf ServicePRO 5 Year Date of Purchase Commercial Warranty [more info] +$281.98

All U-Line Wine Captain Models use LowE coated, argon gas filled thermopane glass to protect and preserve wines from potentially harmful UV rays and efficiently hold and maintain temperatures.
