Kegco Hot Draft 61" Wide Stainless Steel Commercial Hot Draft ® Tap Coffee KegeratorModel: XCK-HDT-2460S
- Simultaneously dispense hot and cold nitro coffee while also dispensing other beverages from additional kegs
- Heated at the point of dispense, each cup is heated on demand with user-friendly controls and adjustable heat settings
- Nitro kegged coffee with prolonged shelf life to minimize waste
- Two knockkouts allow you to mount your CO2 or nitrogen tank remotely
- ETL listed commercial-grade unit is 25% more energy efficient to save you money every month
The Kegco XCK-2460S Commercial Kegerator is perfect for pubs, restaurants, bars and events. This keg cooler has enough interior space to house three full-size kegs or a combination of smaller kegs. With the ability to mount two draft arms, the beer dispenser can be set up to dispense from 2 up to 8 kegs at once! Forced air refrigeration keeps the beer in the kegs ice cold and and hoses direct cold air into each beer tower to ensure the line is cooled all the way to the faucet. These kegerators include two heavy duty adjustable shelves, providing the ultimate in versatility. You can store cans and bottles or keep mugs chilled on one side while dispensing multiple 5 gallon kegs from the other side! Built-in drip trays catch any drops after you fill a glass and route to an external drain, making daily maintenance a breeze.
The sturdy XCK-2460S is designed to withstand the demands of commercial use. Featuring an attractive stainless steel interior and exterior and a rubber floor mat that reduces the shock of the heavy kegs on the stainless steel floor, it is sure to provide reliable performance for years. Lights inside the unit conveniently illuminate the cabinet to make adjustments to your dispense system effortless. The hoses inside the cabinet that direct cool air into the draft arm and drain beer from the drip tray to an external drain are efficiently tucked out of the way. The cooling unit is serviceable from the front of the kegerator, allowing it to be used in both freestanding and built-in applications.
This kegerator can fit three Full Size or Pony Kegs, up to five Quarter Slim Kegs, and up to nine 5 gallon kegs (with an external CO2 tank. View the Features tab for possible keg configurations. Due to the versatility of the storage area inside the kegerator, we have set up custom addons below for you to customize your dispense system. If your beer distributor will be providing your dispense kit, simply choose the tower option that works for you.
- Keg Storage Capacities:
- Three (3) Full Size / 1/2-Barrel (15.5 Gal.)
- Three (3) Pony Size / 1/4-Barrel Short (7.75 Gal.)
- Five (5) 1/4-Barrel Slim (7.75 Gal.) or
- Nine (9) 1/6-Barrel (5.23 Gal.)
- 2-Door Design
- Digital Temperature Display
- Continuous Cold Air Channeled Through Tower to Ensure Cold Product
- Heavy-Duty Stainless Steel Exterior and Top
- Two Built-In Drip Trays with External Drains
- Stainless Steel Interior Walls and Ceiling
- Rubber Floor Mat Reduces Shock on Cabinet Interior
- Magnetic Gaskets Provide Positive Door Sealing
- Self-Closing Doors with Locks
- Interior Lighting
- Refrigeration System Utilizes Ozone Friendly R134a Refrigerant
- CFC-Free Foamed-in-Placed Polyurethane Insulation
- Designed for Built-in or Freestanding Use
- Refrigeration System Accessible from the Front
- Two Knockouts for Remote CO2 or Nitrogen Tank
- 25% More Energy Efficient Design Saves You Money Each Month!
- ETL Listed for Commercial Use
- Maximum Ambient Temperature: 90 degrees Fahrenheit
- Minimum Ambient Temperature: The lowest temperature you want to store your kegs at. The unit does not have a heater, so if the ambient temperature is lower than the set temperature, the internal temperature will match the external temperature.
Some configurations require external tank mount.
|Temperature Range||120 - 180 degrees Fahrenheit|
|Pressure Range||20 PSI - 40 PSI|
|Wattage||4.8 kW/4.4 kW/3.6 kW|
|Voltage||240 V/230 V/208 V|
|Amperage||20 A/20 A/18 A|
|Minimum Flow Rate|
|Minimum Flow Rate||0.15 GPM|
|Patents||#10,092,132, #10,939,781, #10,203,131 B2|
Labor - 12 MonthsLIMITED ONE YEAR WARRANTY
For one year from the date of purchase by the original owner, Kegco will, at its option, repair or replace any part of the unit, which proves to be defective in material or workmanship under normal use. During this period Kegco will provide all parts and labor necessary to correct such defects free of charge, so long as the unit has been installed and operated in accordance with the written instructions in this manual. Kegco will provide you with a reasonably similar replacement product that is either new or factory refurbished. In rental or commercial use, the warranty period is 90 days. All Kegco Appliances of 3.5 cubic feet capacity or less must be brought/sent to the appliance service shop for repair.
Parts - 60 MonthsLIMITED SECOND THROUGH FIFTH YEAR WARRANTY:
For the second through the fifth year from date of original purchase, Kegco Products will provide a replacement compressor free of charge due to a failure. You are responsible for the service labor and freight charges. In rental or commercial use, the limited compressor warranty is one year and nine months. Cost to move the appliance to the servicers’ shop and back to the user's home, as may be required, are the user's responsibility.
Additional DetailsWHAT IS NOT COVERED:
- Content losses of food or other, due to spoilage.
- Incidental or consequential damages.
- Parts and labor costs for the following will not be considered as warranty:
- Door springs, and/or frames.
- Inner door panels, door rails and/or door supports.
- Light bulbs and/or plastic housing.
- Plastic cabinet liners.
- Punctured evaporator that voids the warranty on the complete sealed system.
- Repairs performed by unauthorized servicers.
- Shipping and handling costs associated with the replacement of the unit.
- Service calls that do not involve defects in material or workmanship such as customer education, door reversal, or proper installation.
- Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense for service call to remote areas, including the State of Alaska.
- Service calls that are related to external problems, such as abuse, misuse, inadequate electrical power, accidents, fire, floods, or acts of God.
- Replacement of house fuses or resetting circuit breakers.
- Failure of the product if it is used for other than its intended purpose.
- This warranty does not apply outside the Continental USA.
